Triple screw pump power unit

OIL-IMMERSED DOUBLE SPEED POWER UNIT

(Dual-valve JL36 Triple-valve JL36/JL36-89)

Specifically designed for villas, luxury residences, and customized home elevators, this hydraulic power unit features a high-pressure triple-screw  pump combined with intelligent variable-frequency drive. Integrating innovative mechatronic and hydraulic design, it achieves whisper-quiet  operation (≤45 dB), zero pulsation, and zero resonance—setting a new benchmark for home elevator hydraulic power units.

Triple-screw pump

Class A Screw Reduces noise by 10%. The motor and pump are fully submerged in oil during  operation, isolating 98% of noise (tested per ISO 3744) and meeting residential nighttime noise  standards (GB 3096-2008, Class 1 area).

The combination of a three-screw continuous seal and an accumulator dynamic compensation limits  pressure fluctuation to just ±0.05 MPa, completely eliminating pipeline-induced vibration transmitted  to the car and resolving the resonance-related noise that occurs during elevator ascent 02

IE4 High Efficiency Variable Frequency Energy Saving Motor

Energy efficiency is 15% higher than standard motors. Supports speed adjustment as fine as 0.01 Hz.

Wide voltage compatibility (three-phase 220 V / 380 V ±15%) adapts to different power grid conditions.

Max 3kW single phase motor. 03

Vibration-damping and noise-reducing structure

Primary: Floating bearings and direct motor-pump coupling technology between the motor and pump  body achieve a vibration attenuation rate of ≥90%.

Secondary: The entire unit is floatingly mounted on an elastic base (natural frequency <5 Hz), resulting  in a vibration transmissibility of ≤3%. 04

Updated valve blocks

With one hand to operate the manual descend switch (speed adjustable from 0.1 to 0.15 m/s).

Equipped with mechanical self-locking to prevent accidental operation. After resetting, the valve  automatically seals with near-zero leakage.
