HIGH-SPEED HYDRAULIC ELEVATOR POWER UNIT

HIGH-SPEED HYDRAULIC ELEVATOR POWER UNIT(JL90：11kW-15kW)

The JL90 hydraulic power pack unit is a high-performance drive system designed for 0.3 m/s high rise hydraulic elevators, offering stable,quiet,  comfortable, and heavy load operation. Equipped with a triple screw pump, a dedicated JL90 valve blockand an oil immersed motor, no need VFD. Elevator ascent achieves smooth  start stop, and seamless operation, with ride comfort rivaling that of mid range traction elevators. The unit supports a rated load of 600 kg and allows flexible load customization for freight elevators. Compact, easy to install and maintain,and  built for long term stability, the JL90 is perfectly suited for high speed, high rise, and heavy load hydraulic elevators.
